Режимы Вентиляции
|
VCV (A/C), PCV (A/C), PRVC (optional), PSV (optional), STANDBY SIMV (VCV) + PSV, SIMV (PCV)+PSV, SIMV (PRVC)+PSV SPONT/CPAP+PSV BIVENT/APRV +PSV (optional) NIV/CPAP, NIV-T, NIV-S/T
|
|
Расширения
|
Apnea ventilation, Pressure and Flow trigger, Automatic Tube Compensation (ATC), Smart suction Manual breath, Insp/Exphold, Screen freeze, Nebulization, Lung recruitment
|
|
Объем вдоха (VT) |
20-2000ml
|
|
Частота дыхания (RR) |
1 to 80 bpm
|
|
Вдохновение Продолжительность (Ti) |
0.2 to 9 s (adult), 0.2 to 5 s (pediatric)
|
|
Минутный Объем Дыхания (Поток) |
0 to 100 L/min (pediatric), 0 to 180L/min (adult)
|
|
PCV |
5 to 70 mbar (or cmH2O)
|
|
PEEP |
0 to 35 mbar (or cmH2O)
|
|
Tslope |
0 to 2 s
|
|
Концентрация O2 (FiO2) |
21 to 100 Vol%
|
|
Триггер Чувствительность |
0.5 to 20 L/min (Flow trigger), -20 to 0 mbar (or cmH2O) (Pressure trigger)
|
|
Коэффициент I / E (Вдох / Выдох) |
1/10 - 4/1
|
|
Apnea alarm time |
10-60 seconds
|
|
Контролируемые Параметры
|
Pressure values Pplat, Ppeak, Pmean, Pmin, PEEP Volume/Flow values VTI, VTE, MV, MVe, MVspont Time values ftotal, fspont, I:E Loops Pressure-Volume loop, Pressure-Flow loop, Flow-Volume loop Inspiratory O2 concentration (FiO2), End-expiratory CO2 concentration (etCO2) Compliance (dynamic & static), Resistance (R), MVleak, RSBI, WOB, I:E, Vdaw, PEEPi
|
|
Предупредительный сигнал
|
Expiratory minute volume (MV) High/Low, Airway pressure (Paw) High/Low, VTe Low, PEEP High/Low, Insp. O2 concentration (FiO2) High/Low, End-expiratory CO2 concentration (etCO2) High/Low, fspont High, Apnea alarm, Disconnection, Flow sensor error, Gas supply, Electrical supply & battery failure, Exhalation obstruction, Apnea backup for low frequency alarm |
